Name: 45KW High Temperature Gas Steam Generator Customized Installation
Brand: Foshan Zhongji Environmental Protection Equipment Co., Ltd.
SKU: SZQ-ZBTGWR-50
Price: 1600 USD
Availability: InStock

Home > products > Gas Steam Generator >

45KW High Temperature Gas Steam Generator Customized Installation

45KW Gas Steam Generator

Gas Steam Generator Customized

45KW High Temperature Steam Generator

Place of Origin:

Guangdong of China

Brand Name:

Zhongji

Certification:

ISO, GB

Model Number:

SZQ-ZBTGWR-50

Request A Quote

45KW High Temperature Gas Steam Generator Customized Installation

Product Details

Burner Brand:

Customized

Design Pressure:

0.7Mpa Max.

Fuel Consumption:

Depends On LPG Gas Or Natural Gas

Fuel Type:

Gas

Installation Type:

Customized

Material:

Stainless Steel

Pressure Level:

High Pressure

Product Name:

High Pressure Gas Steam Generator

Steam Capacity:

50-60kg/hr

Steam Temperature:

110-170

Payment & Shipping Terms

Minimum Order Quantity

1 set

Price

USD1600/set

Packaging Details

carton box and wooden case

Delivery Time

5-8 working days

Payment Terms

Western Union, MoneyGram

Supply Ability

1000set/month

45KW High Temperature Gas Steam Generator Customized Installation

Get Best Price

75kw Natural Gas Steam Generator Home Use 0.3Mpa Low Pressure

Get Best Price

Stainless Steel Horizontal Steam Generator 50HZ Gas Powered Steam Generator GB

Get Best Price

Video

High Pressure LPG Steam Generator 0.7Mpa Gas Fired Steam Boiler

Get Best Price

0086-13726653830

lilychan85@163.com

Contact Now

Product Description

Product Name:Natural Gas Or Liquefied Gas Fired Steam Boiler Low Pressure Steam Generator

Item No.: SZQ-ZBTGWR-50

Description of product :

1. Small in size, save space

2. Have a external water tank, support artificial watering when there is no running water in the inner water tank.

3. Heating automatic. Simple circuit, easy to maintain

4. The adjustable pressure controller can be adjusted by your need.

5. High quality heater, can adjust power

6. Full stainless steel materials

Five security:

1. Stop heating automatically when reaching the setting temperature

2. Stop heating automatically when reaching the setting pressure

3. The safety valve relief automatically when the pressure reached the setting pressure

4. Stop heating automatically when there is no water in the tank

5. Stop heating automatically when stainless steel mechanical adjustable pressure controller reached the setting pressure.

Technical Parameter

SZQ-ZBTGWR-50 High Temperature Type
Specification	30P
Evaporation/hour	58KG
Power(thermal load)	45KW
Thermal efficiency	94%
Rated steam pressure	0~0.7MPa
Machine size(mm)	810X520X1150mm
Water capacity	23L
Steam temperature	100-170℃
Diameter of steam outlet	DN15
Diameter of gas inlet	DN20
Diameter of water intake	DN15
Diameter of sewage outlet	DN40
Control system	Automatic control
Water refill method	External water pump
Power of water pump	550W
Diameter of safety valve	DN15
Gas consumption/hour	LPG gas:3.8KG
Gas consumption/hour	natural:4.5m³
Gas pressure	LPG gas:2800Pa
Gas pressure	Natural gas:2000Pa
gas diameter of natural gas	commercial gas:1.15mm
gas diameter of natural gas	civilian gas:1.53mm
Power supply	Voltage:220V
Power supply	frequency:50Hz
Gas proportional valve	24V
Fan power	120W
Ignite	220V electronic pulse ignition
Structure	Wall hanging/vertical
Materials	The inner liner is 304 stainless steel 3mm thick, the fire tube is 304 thick 1.5mm seamless tube welded, the shell is 201 stainless steel material
Protective device	External mechanical safety valve, built-in electronic control pressure switch, temperature setting limit protection
